A toy to visualize recursive function calls
       2024-06-29
       Last edit: 2024-06-29
       ---------------------

       Recently, I did a little project in
  HTML Python
        to visualise function calls, especially recursive functions.

       It takes the form of a
  HTML Python
        decorator applied to the desired functions. The data structure used is fairly basic, a tree with nodes that have a parent and an indefinite number of children. Each node represents a function call, and the nodes also include the arguments passed to the function when it is called and, optionally, a return value.

       To generate a visual and have an overview of all the function calls, I used
  HTML Graphviz
        to manage a graph and save it as a file (DOT, SVG, PNG, etc.).

       The decorator also supports memoization, which can also be represented on the final visual.

       ## How is it used?

       These are two clear examples of how the decorator is used.

       ```python
       from callviz.core import callviz, set_output_dir

       set_output_dir("out")

       @callviz(
         _format="png",
         memoization=True,
         open_file=True,
         show_node_result=True,
       )
       def fib(n: int):
           if n < 2:
               return n

           return fib(n - 2) + fib(n - 1)

       @callviz(_format="png", show_link_value=False)
       def rev(arr, new):
           if arr == []:
               return new

           return rev(arr[1:], [arr[0]] + new)

       fib(5)
       rev(list(range(6, 0, -1)), [])
       ```

       ## Links

  HTML https://github.com/theobori/callviz
