#Post#: 57459--------------------------------------------------
Re: CYD
By: parksy64 Date: April 15, 2013, 3:27 pm
---------------------------------------------------------
Nice!
#Post#: 57461--------------------------------------------------
Re: CYD
By: Lurch Date: April 15, 2013, 3:30 pm
---------------------------------------------------------
It didnt look that bad before I took it off ::)
#Post#: 57462--------------------------------------------------
Re: CYD
By: Drew Date: April 15, 2013, 3:31 pm
---------------------------------------------------------
Just acquired a strengthened rear axle like that.
Going to give it an all-over tap and I may lob it on 'Tommy',
which sheds the odd tear from the diff-pan.
Keep it up, Pete!
#Post#: 57465--------------------------------------------------
Re: CYD
By: Lurch Date: April 15, 2013, 3:37 pm
---------------------------------------------------------
So, Mucky kindly donated a casing which I cleaned and painted
I removed the n/s rear hub to find this goo!
HTML http://i308.photobucket.com/albums/kk329/lr229/Photo0076_zpsb9d1ff68.jpg
Supprised the brakes were working they were that contaminated,
but they did and he always pulled up straight
Tha lands were worn both sides and were replaced
HTML http://i308.photobucket.com/albums/kk329/lr229/Photo0079_zpsc0a6d83f.jpg
#Post#: 57471--------------------------------------------------
Re: CYD
By: Lurch Date: April 15, 2013, 3:51 pm
---------------------------------------------------------
Much cleaning and painting of parts then took place, the
replacement casing then fitted with bling galvy pipe protectors
HTML http://i308.photobucket.com/albums/kk329/lr229/Photo0097_zpsb7ede6cc.jpg
The axle breather was blocked and the n/s brakepipe has a nasty
V shaped creviss in it, they will be replaced.
The o/s wheel cylinder was off the front of an 88 so i have
splashed out on a new one of correct sizage
NOS riveted shoes were found in my stash 8)
HTML http://i308.photobucket.com/albums/kk329/lr229/Photo0101_zps77296444.jpg
And fitted after the new land
HTML http://i308.photobucket.com/albums/kk329/lr229/Photo0102_zps71c706ac.jpg
I need to get some new locknuts for the backplates and the U
bolts
#Post#: 57493--------------------------------------------------
Re: CYD
By: Luke Date: April 15, 2013, 5:26 pm
---------------------------------------------------------
8)
Just been doing exactly this with a new axle for my 80"
#Post#: 57503--------------------------------------------------
Re: CYD
By: Boris Date: April 15, 2013, 11:47 pm
---------------------------------------------------------
Have to say CYD looks bang tidy :giddy: I take it that not all
axles have that strengthening on ? :-?
Gary
#Post#: 57521--------------------------------------------------
Re: CYD
By: Flatcap Date: April 16, 2013, 6:20 am
---------------------------------------------------------
Damn fine beast Lurch! Your tdi looks good but did you have to
fit the fan or was it a precaution incase of global warming?
Now...pray tell, what intercooler is fitted cause its nice &
neat.(P38?)
#Post#: 57546--------------------------------------------------
Re: CYD
By: Lurch Date: April 16, 2013, 1:20 pm
---------------------------------------------------------
As far as strengthened axles, all the series 2, 2a and 3s Ive
seen have them, I guess S1s may be different :-\
The fan was fitted after LATP 12 as he was getting rather hot on
the downhill run home with the maggot on tow, its working of a
thermal switch or should be as it hasn't come on yet.
The intercooler is off a TD5 (T D 5) and fits nicely in the
front panel, its bigger than the 200/300 and much easier to fit
(slimmer), no staggering of the radiator frame which is cut down
to fit just the rad.
Replacing parts should be easy as everything is made to fit
standard parts, ie, no welding intercooler necks etc
I basically cobbled together everybody else's ideas that i liked
:)
#Post#: 57548--------------------------------------------------
Re: CYD
By: Drew Date: April 16, 2013, 1:26 pm
---------------------------------------------------------
Porny brake shoes.
*****************************************************
